Vickers Manual Control Valve
. DG3.H8; 30 and 10 Series, Pilot Operated. DG17.H8; 30 and 10 Series, Manually Operated. DG5.H8; 50 and 30 Series, Solenoid Controlled, Pilot Operated. ISO 4401 Size 08 DG.H8 valves are used primarily for controlling the starting, stopping and direction of fluid flow. Basically, six series of valves are available grouped into DG.S moderate pressure versions and DG.V high pressure versions.
- Vickers Manual Control Directional Valve
- Vickers Manual Control Valve And Drain Lines
- Vickers Manual Control Valve
There is a choice of up to 18 different spools, dependent on valve configuration. These include meter-in and meter-out spools, and regeneration types that can obviate extra valves essential in traditional circuit arrangements.
Vickers Manual Control Directional Valve
All spools have been designed to provide good low shock, fast response characteristics which can be enhanced by optional stroke and/or pilot choke adjustments. Mechanical Actuators and Directional Control Valves. DG2S2/4-01.-52 Plunger Operated. DG16S2/4-01.-52 Deceleration Valve. DG1S2/4-01.-50 Knob Operated.
DG17S2/4-01.-50 Lever Operated. NFPA D05, ISO-4401-05 The mechanical directional control valves described in the available brochure are:. Two & Four-way cam operated valves DG2/ 16S4-01. Knob & Lever operated valves DG1/ 17S4-01 Mechanical operation used by these valves is achieved by either hand actuation or roller cam. Many applications that use the roller cam feature are deceleration valves to control the movement of a load. These valves are generally used to control the direction of flow in a hydraulic circuit.
Download champak cd games, free online games, flash games, free flash games, online games, play game. Sep 9, 2017 - Name: CHAMPAK GAMES CD FREE DOWNLOAD Downloads: 1469. Update: December 24, 2015. File size: 13 MB. CHAMPAK GAMES CD FREE DOWNLOAD. GAMES DOWNLOAD FREE CD CHAMPAK. THE CHRONIC DISEASES HAHNEMANN.PDF; DRIVER CPC BUS AND TRUCK THEORY TEST;.
This, in turn, would control the direction of movement of a hydraulic cylinder, or the rotation of a fluid motor. Features and Benefits. Suitable for the most demanding industrial applications with flow capacities up to 380 l/min ( 100 USgpm ) and rated pressure of 210 bar (3000 psi). High pressure and flow capability for. Maximum cost-effectiveness. Low shock characteristics to maximize machine life. Solid cast body and core passages for maximum strength and minimal pressure drop.
Designed and backed by Vickers, with over 70 years as the global leader in fluid power and motion control. DG3V-5, 10 Series, Pilot Operated DG5V-5, 10/20 Series, Solenoid Controlled, Pilot Operated ISO 4401-05-05-0-94 These valves are used for controlling the starting, stopping and direction of fluid flow. Two types of control are available:. Hydraulic pilot pressure ( DG3V-5 models). Integrally-mounted solenoid operated pilot valves ( DG5V-5 models) comprising spring-offset, spring-centered and detented versions.
Vickers Manual Control Valve And Drain Lines
Pilot pressure and drain can be independently configured for internal or external connection. All spool types have been designed to provide good low-shock, fast-response characteristics which can be enhanced by an optional pilot choke module to control the speed of travel of the main spool. DG3V-7, 20 Series, Pilot Operated. DG5V-7, 40 Series, Solenoid Controlled, Pilot Operated. ISO 4401 Size 07 DG.V-7 valves are used primarily for controlling the starting, stopping and direction of fluid flow. Two series of valves, DG5V solenoid controlled, pilot operated and DG3V pilot operated models are available with a choice of 18 different spools. These include meter-in and meter-out spools and a regeneration type that can obviate extra valves essential in traditional circuit arrangements. All spools have been designed to provide good low shock, fast response characteristics which can be enhanced by optional stroke and/or pilot choke adjustments.
Vickers Manual Control Valve
NFPA D08/ D10, ISO-4401-08/10 These valves are generally used to control the direction of flow in a hydraulic circuit. This, in turn, would control the direction of movement of a hydraulic cylinder, or the rotation of a fluid motor.
Features and Benefits:. Suitable for the most demanding industrial applications with flow capacities up to 946 l/min (250 USgpm) and rated pressure of 310 bar (4500 psi). Available with a wide variety of spool and spring arrangements, stroke and pilot choke adjustments, integral check valves, and port orifices. Solid cast body and core passages for maximum strength and minimal pressure drop. Designed and backed by Vickers, with over 70 years as the global leader in fluid power and motion control.
